FAG 6005.2RSR.C3 Deep Groove Ball Bearing
New
In stock18 unitsReady to ship
Deep Groove Ball Bearing
The FAG 6005-2RSR-C3 deep groove ball bearing features a 25 mm bore, 47 mm outer diameter, and steel sheet metal cage. With a dynamic load rating of 10,700 N and a contact seal on both sides, it is built for high-speed, high-load applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 6005-2RSR-C3 “ Deep Groove Ball Bearing
The FAG 6005-2RSR-C3 deep groove ball bearing offers excellent load handling and smooth operation in a variety of industrial and mechanical applications. With a contact seal on both sides and C3 clearance, it is designed to perform reliably in high-speed and high-load environments.
Manufacturer: FAG
Type: Deep Groove Ball Bearing
Model: 6005-2RSR-C3
| Bore Diameter (d) | 25 mm |
| Outer Diameter (D) | 47 mm |
| Width (B) | 12 mm |
| Dynamic Load Rating (Cr) | 10,700 N |
| Static Load Rating (C0r) | 5,900 N |
| Fatigue Load Limit | 315 N |
| Limiting Speed | 8,400 1/min |
| Cage | Steel sheet metal |
| Sealing | 2RSR, Contact seal on both sides |
| Clearance | C3 |
| Operating Temperature | -20 to 100°C |
