FAG 61810-2RZ-Y-P5-C2 Deep Groove Ball Bearing
New
In stock17 unitsReady to ship
Deep Groove Ball Bearing
FAG Schaeffler 61810-2RZ-Y-P5-C2 Deep Groove Ball Bearing with a 50 mm bore, 65 mm outer diameter, and 7 mm width. It offers a high dynamic load rating of 7,200 N and a high-speed limit of 12,900 1/min, ideal for demanding industrial applications.2005061810-2RZ-Y-P5-C27BallbearingbearingsboreDeepDynamicFagGrooveHigh-SpeedIndustrialLoadmmNSchaeffler
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG Schaeffler 61810-2RZ-Y-P5-C2 Deep Groove Ball Bearing
The FAG Schaeffler 61810-2RZ-Y-P5-C2 Deep Groove Ball Bearing is designed for high-speed applications, offering reliable performance under both radial and axial loads. Its precision design ensures long-lasting durability and smooth operation in various industrial environments.
Manufacturer: FAG Schaeffler
Model: 61810-2RZ-Y-P5-C2
Type: Deep Groove Ball Bearing
| Bore Diameter (d) | 50 mm |
| Outer Diameter (D) | 65 mm |
| Width (B) | 7 mm |
| Basic Dynamic Load Rating, Radial | 7,200 N |
| Basic Static Load Rating, Radial | 6,300 N |
| Fatigue Load Limit, Radial | 440 N |
| Limiting Speed | 12,900 1/min |
| Reference Speed | 6,400 1/min |
| Sealing | 2RZ, Non-contact seal on both sides |
| Cage | Y, Brass sheet metal |
| Clearance | C2 |
| Tolerance Class | P5 |
