FAG 6209.2ZR.C3 Deep Groove Ball Bearing
Manufacturer: Schaeffler FAG
Type: Deep Groove Ball Bearing
Model: 6209 2ZR.C3
Dimensions
Bore Diameter d: 45 mm
Outer diameter D: 85 mm
Width B: 19 mm
Dynamic Cr: 33000 N
Static C0r: 20300 N
Fatigue load limit: 1400 N
Limiting speed: 9800 rpm
Reference speed: 8900 rpm
Cage: steel sheet metal
Sealing: 2Z, non-contact shield on both sides
Radial internal clearance: C3
