FAG 6304.2ZR.C3 Deep Groove Ball Bearing
Manufacturer: Schaeffler FAG
Type: Deep Groove Ball Bearing
Model: 6304 2ZR.C3
Dimensions
Bore Diameter d: 20 mm
Outer diameter D: 52 mm
Width B: 15 mm
Dynamic Cr: 16900 N
Static C0r: 7900 N
Fatigue load limit: 540 N
Limiting speed: 16800 rpm
Reference speed: 14400 rpm
Cage: steel sheet metal
Sealing: 2Z, non-contact shield on both sides
Radial internal clearance: C3
