FAG 6307.2ZR.C3 Deep Groove Ball Bearing

Manufacturer: Schaeffler FAG
Type: Deep Groove Bearing
Model: 6307 2ZRC3

Dimensions
Bore Diameter d: 35 mm
Outer diameter D: 80 mm
Width B: 21 mm
Dynamic C_r: 35500 N
Static C_0r: 19100 N
Fatigue load limit: 1290 N
Limiting speed: 10500 rpm
Reference speed: 9900 rpm
Cage: steel sheet metal
Sealing: 2ZR, Non-contact shield on both sides
Radial internal clearance: C3
