FAG 6310.2ZR.C3 Deep Groove Ball Bearing

Manufacturer: schaeffler FAG

Type: Deep Groove Ball Bearing

Model: 6310 2ZR.C3

Replaces: 6310-2Z-C3

Dimensions

Bore Diameter d: 50 mm

Outer diameter D: 110 mm

Width B: 27 mm

Dynamic C_r: 68000 N

Static C_0r: 38500 N

Fatigue load limit: 2650 N

Limiting speed: 8000 rpm

Reference speed: 7700 rpm

Cage: steel sheet metal

Sealing: 2Z, Non-contact shield on both sides

Radial internal clearance: C3
