FAG 7210B.TVP.UA Angular Contact Ball Bearing
New
In stock3 unitsReady to ship
Angular Contact Ball Bearing
FAG 7210B.TVP.UA Angular Contact Ball Bearing features a 50 mm bore diameter and 90 mm outer diameter. It is designed for precision applications with a 40° contact angle and high dynamic load capacity of 41,500 N.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
FAG 7210B.TVP.UA Angular Contact Ball Bearing
The FAG 7210B.TVP.UA Angular Contact Ball Bearing is designed for precision and high-speed applications, offering high dynamic load ratings and reliable performance under axial and radial loads.
Manufacturer: FAG
Type: Angular Contact Ball Bearing
Model: 7210B.TVP.UA
| Design | UA, bearing set with small axial internal clearance |
| Bore Diameter | 50 mm |
| Outer Diameter | 90 mm |
| Width | 20 mm |
| Contact Angle | 40° |
| Dynamic Load Capacity (Cr) | 41,500 N |
| Static Load Capacity (C0r) | 28,500 N |
| Fatigue Load Rating | 1,970 N |
| Limiting Speed | 10,300 1/min |
| Reference Speed | 7,600 1/min |
| Cage | TVP; Solid cage made of glass-fiber reinforced polyamide PA66 |
