FAG 7305B.MP.UA Angular Contact Ball Bearing

Manufacturer: FAG

Type: Angular Contact Ball Bearing

Model: 7305 B.MP.UA

Replaces: 7305-B-XL-MP-UA, 7305-B-MP-UA



Dimensions

Bore Diameter d: 25 mm

Outer diameter D: 62 mm

Width B: 17 mm

Basic load ratings:

Dynamic C_r: 28000 N

Static C_0r: 14200 N

Fatigue load limit C_ur: 990 N

Contact Angle: 40°

Limiting speed: 20500 rpm

Reference speed: 9900 rpm

Cage: MP solid brass cage, ball guided

Bearing with matched conditions for fitting in pairs: UA, bearing set with small axial internal clearance
