FAG 7305B.2RS.TVP Angular Contact Ball Bearing

Manufacturer:  FAG
Type:  ANGULAR CONTACT BALL BEARING
Model:  7305B-2RS-TVP

Dimensions
Bore Diameter d: 25 mm
Outer diameter D: 62 mm
Width B: 17 mm
Basic load ratings:
Dynamic C_r: 30000 N
Static C_0r: 15800 N
Fatigue load limit C_ur: 1100 N
Contact Angle: 40°
Limiting speed: 7100 1/min
Cage: TVP, solid cage made of glass-fiber reinforced polyamide PA66
Tolerance class: P6, Class6 (P6), better than PN
Sealing: 2RS, Contact seal on both sides
Lubricant: GA14
Design variant: B
