Festo 170682 On/Off Valve
Used
In stock2 unitsReady to ship
On/Off Valve
The Festo HE-D-MIDI on/off valve features a manual actuation piston gate design, 3/2 double solenoid function, and a wide operating pressure range. It is designed for in-line installation in compressed air systems, made from die-cast aluminum with RoHS compliance.3/2ActuationAirCompressedDoubleFestoGateHE-D-MidiManualOn/OffPistonPneumaticRoHS-CompliantsolenoidValve
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Festo HE-D-MIDI “ On/Off Valve
The Festo HE-D-MIDI on/off valve is a high-quality piston gate valve designed for manual actuation in compressed air systems. With a 3/2 double solenoid valve function and RoHS-compliant materials, it provides reliable and versatile performance in industrial environments.
Manufacturer: Festo
Type: On/Off Valve
Model: HE-D-MIDI
Part No: 170682
| Design | Piston gate valve |
| Type of Actuation | Manual |
| Sealing Principle | Soft |
| Exhaust-Air Function | Without flow control option |
| Manual Override | None |
| Valve Function | 3/2 double solenoid |
| Operating Pressure | 0 MPa / 1.6 MPa, 0 bar / 16 bar |
| Operating Medium | Compressed air |
| Lubricated Operation | Possible |
| Material Compliance | RoHS-compliant |
| Ambient Temperature | -10 to 60 °C |
| Mounting Type | In-line installation with accessories |
| Mounting Position | Optional |
| Flow Direction | Non-reversible |
| Pneumatic Connection (Port 3) | G1/4 |
| Material Seals | NBR |
| Material Housing | Die-cast Aluminum |
