Festo 30457 Proximity Sensor
Proximity Sensor
The Festo SMEO-1-B proximity sensor features magnetic reed technology with a 0.5 ms response time, 250 V AC / 200 V DC operation, and an IP67 enclosure rating. Ideal for precision automation applications.Festo SMEO-1-B Proximity Sensor
The Festo SMEO-1-B is a high-performance proximity sensor designed for precise object detection using a magnetic reed measuring principle. With a fast 0.5 ms switch-on time and a maximum switching frequency of 500 Hz, it ensures rapid response times in automation applications. The sensor operates at 250 V AC / 200 V DC with a maximum output current of 1000 mA, making it suitable for demanding industrial environments.
Its IP67 enclosure rating provides excellent protection against dust and moisture, ensuring durability in harsh conditions. The 2.5 m PVC cable allows for flexible installation, and its compact 15.5 x 14 x 34 mm size makes it ideal for space-constrained applications.
Manufacturer: Festo
Type: Proximity Sensor
Model: SMEO-1-B
Part No.: 30457
| Measuring Principle | Magnetic reed |
| Switch-on Time | 0.5 ms |
| Operating Voltage | 250 V AC / 200 V DC |
| Max. Output Current (AC/DC) | 1000 mA |
| Power | 40 W |
| Switching Frequency | 500 Hz |
| Switching Output | Normally open |
| Connector Type | Cable, 2.5 m |
| Enclosure Rating | IP67 |
| Material Cable Sheath | PVC |
| Ambient Operating Temperature | -20 to 70°C |
| Dimensions (W x H x D) | 15.5 x 14 x 34 mm |
