Festo DGC-32-320-G-PPV-A Linear Actuator

Manufacturer: FESTO

Type: Linear Actuator

Model: DGC-32-320-G-PPV-A

Part No: 532448

Materials

• Cover: Wrought Aluminum Alloy
• Seals: NBR TPE-U(PU)

Piston Diameter: 32 mm

Cushioning: Adjustable at Both Ends

Stroke: 320 mm

Cushioning Length: 17.5 mm

Operating Pressure: 2…8 bar

Ambient Temperature: -10…60 °C

Pneumatic Connection: G1/8

Constructional Design: Pneumatic Linear Drive with Slide

Mode of Operation: Double-Acting

Guide: Recirculating Ball Bearing Guide

Position Sensing: For Proximity Sensor

Magnet: with Magnet

Type of Mounting: with Accessories

Weight: 3.82 kg
