Gentec P-Link RS-232-AT Laser Power Meter
Used
In stock1 unitReady to ship
Laser Power Meter The GENTEC P-LINK RS-232-AT is a laser power meter with USB and RS-232 communication, PC-LINK software, real-time monitoring, and statistical analysis.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Power Range (Thermal Head) | 1 mW to 10 kW |
| Power Range (Photo Detector Head) | 300 pW to 3 W |
| Resolution (Digital) | 5 µW on the 30 mW scale |
| Statistics | Current Value, Max., Min., Avg., Std. Dev., RMS & PTP |
| Software | Full Window Application PC-LINK Software |
| Communication | USB and RS-232 |
| Communication Between Host Computer and P-LINK | USB and RS-232 |
| Digital Display | Computer Screen |
| Data Storage | Limited by PC Capacity |
| Data Displays | Real Time, Histogram, Statistics |
| User Input Correction Factors | 1 Multiplier and 1 Offset |
| Analog Output | 0–2 V, Full Scale, ± 1% |
| Internet Upgrades | PC-LINK Upgrades via USB or RS-232 |
| PC Serial Commands | USB and RS-232 |
| Dimensions | 86 x 58 x 27 mm |
| Stock Key | CON003 |
| Condition | Used |
| SKU | 1103886 |
| Weight | 0,11 |
