HPI Hydroperfect International P1BAN1002CL10B01N Gear Motor

Manufacturer: Hpi Hydroperfect International

Type: Gear Motor

Model: P1BAN1002CL10B01N

Order Code: 2123078274

Size: 2.05

Type of The Series: 1

CAPACITY In The SERIES: 2.05 cc/rev

Output flow at 1500 rpm: 3.07 l/min

Direction Rotation: Clockwise

Mounting Flange: Holes

Flat Front Body: Without Tightness on Spigot Joint

Ports Location: Square location

Rear Body: Not Port on Rear Body (Standard)

Max. Work Pressure: 255 bar

Peak Pressure: 300 bar

Shaft Type: Tapered Shaft

Shaft Seal: Nitrile

Max Speed: 8000 rpm

Weight: 0.93 Kg
