Hubner Berlin OG 9 D 500 Incremental Encoder

In stock1 unitReady to ship

INCREMENTAL ENCODER

Hubner Berlin OG 9 D 500 is a high-precision incremental encoder with solid shaft, 500 PPR resolution, HTL signal output, and terminal box connection, built for industrial reliability.

Manufacturer
HUBNER BERLIN
SKU
1003642
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

HUBNER BERLIN OG 9 D 500 INCREMENTAL ENCODER

The Hubner Berlin OG 9 D 500 is a robust incremental encoder engineered for precision, durability, and efficient signal output in demanding industrial environments. Ideal for applications requiring accurate position and speed detection.

Manufacturer: Hubner Berlin

Type: Incremental Encoder

Model: OG 9 D 500

Serial No.: 1 199 460

Size (Flange)115 mm
Flange DesignEURO flange B10
Shaft TypeSolid Shaft
Shaft Diameter11 mm
Voltage Supply9 / 30 VDC
Resolution500 Pulse per Revolution (PPR)
Max. Operating Speed1200 rpm
Signal OutputHTL
Connection TypeTerminal Box
Switching Frequency120 kHz
Protection ClassIP 55
Temperature Range-30 / 100°C
