Hubner Berlin TDP 0,2 LT-4 Long Life-Tachogenerator
Used
In stock12 unitsReady to ship
349,99$
TACHOGENERATOR
Hubner Berlin TDP0,2LT4 long life-tachogenerator with 60 V ±1% / 1000 min»¹ supply, 9000 min»¹ max speed, solid shaft, IP55 protection, EURO flange B10, and -30 / +130 °C operating range.05302LT460V906466B10BerlinEuroFlangeGeneratorHubnerIndustrialIP55LifelongMeasurementSpeedTachogeneratorTDP0VDE
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Hubner Berlin TDP0,2LT4 Long Life-Tachogenerator
The Hubner Berlin TDP0,2LT4 is a robust long life-tachogenerator designed for reliable speed measurement in demanding industrial applications. Built with a durable aluminum housing, stainless steel shaft, and EURO flange mounting, it ensures high precision, long service life, and compliance with VDE 0530 standards.
Manufacturer: Hubner Berlin
Type: Long life-Tachogenerator
Model: TDP0,2LT4
Part No.: 906466
| Supply Voltage | 60 V ± 1% / 1000 min»¹ |
| Maximum Operating Speed | 9000 min»¹ |
| Shaft Type | Solid shaft |
| Torque | 1.5 Ncm |
| Size (Flange) | 115 mm |
| Connection | Terminal box |
| Armature Resistance | 99 Ω |
| Armature Inductance | 200 mH |
| Protection | IP55 |
| Flange | EURO flange B10, Housing foot B3 |
| Materials | Housing: Aluminum die-cast, Shaft: Stainless steel |
| Standard | VDE 0530 |
| Operating Temperature | -30 / +130 °C |
