IFM IFS205 Inductive Sensor

Manufacturer: IFM

Type: INDUCTIVE SENSOR

Part No.: IFS205

MRN: IFB3007-BPKG/US

Sensing range: 7 mm

Real sensing range: 7 ± 10 % mm

Operating distance: 0 … 5.7 mm

Operating voltage: 0 … 30 V DC

Switching output Current: 100 mA DC

Switching frequency DC: 700 HZ

Voltage drop max.: 2.5 V DC

Electrical design: PNP

Output function: Normally open

Connection: M12 Connector; Contacts: gold-plated

Ambient operating temperature: -25 … 70°C

Protection class: II

Enclosure rating: IP67

Housing: Threaded type

Diameter, Housing length: 12, 50 mm

Material: Brass white bronze coated; sensing face: PBT orange

Mounting: Flush mountable

Weight: 25.2 g
