IFM KB0029 Capacitive Sensor

Manufacturer: IFM

Type: CAPACITIVE SENSOR

Part No.: KB0029

MRN: KB-2020-BBOA

Sensing Range: 4 … 20 mm

Real Sensing Range: 20 ± 10 % mm

Operating Distance: 0 … 16.2 mm

Operating Voltage: 20 … 250 V AC/DC

Switching output current AC: 200 mA , 250 / 100 DC

Switching output current DC: 200 mA , 250 AC / 100 DC

Switching frequency: 25 Hz AC

Switching frequency: 40 Hz DC

Output Function: Normally closed

Connector type, length: PVC Cable, 2m

Protection Class: II

Enclosure rating: IP65

Housing: Cylindrical

Ambient Operating temperature: -25 … 70 °C

Diameter, Housing length: 34, 81 mm

Mounting: Non-flush mountable

Material: PBT

Weight: 258.5 g

Condition: Used
