IFM OG5043 Through-Beam Photoelectric Sensor

Manufacturer: ifm

Type: THROUGH BEAM PHOTOELECTRIC SENSOR /RECIEVER

Part No.: OG5043

MRN: OGE-FPKG/US

Sensing Range: 15 m

Operating Voltage: 10 … 36 V DC

Voltage Drop max.: 2.5 V DC

Switching output current: 200 mA DC

Type of light: Infrared light

Current Consumption: 24 mA

Switching frequency: 500 Hz

Electrical Design: PNP

Output Function: light-on/dark-on mode

Wave length: 880 nm

Connector type: M12 Connector, gold plated contacts

Protection Class: II

Enclosure rating: IP67

Housing: Threaded type

Ambient Operating temperature: -25 … 80°C

Diameter, Housing length: 18, 72 mm

Material: PBT

Lens material: PMMA

Condition: New
