IFM OU5034 Diffuse Reflection Sensor

Manufacturer: ifm

Type: DIFFUSE REFLECTION SENSOR

Part No.: OU5034

MRN: OUT-HPKG

Sensing Range: 200 mm

Operating Voltage: 10 … 55 V DC

Voltage Drop max.: 2.5 V DC

Switching output current: 250 mA DC

Switching frequency: 160 Hz

Electrical Design: PNP

Output Function: Normally closed

Type of light: Infrared light

Wave length: 880 nm

Light spot diameter max.: 180 mm

Connector type: M12 Connector

Protection Class: III

Enclosure rating: IP67

Housing: Rectangular

Ambient Operating temperature: -25 … 80°C

Diameter, Housing length: 28 x 16 x51 mm

Material: PPO modified

Lens material: Glass

Weight: 73.4 g

Condition: New
