INA KRE22-PP-A Stud Type Track Roller

Manufacturer: Schaeffler INA
Type: Stud type track roller with cage, with axial guidance, with Eccentric
Model: KRE22-PPA

Dimensions
Outside diameter D: 22 mm
Fit diameter of roller stud d1: 10 mm
Width B: 36 mm
Width of thrust washer: 13.2 mm
Width, outer ring C: 12 mm
Thread G: M10X1
Basic dynamic load rating, radial: 4500 N
Basic static load rating, radial: 5400 N
Fatigue load limit, radial: 740 N
Speed on permanent grease lubrication: 8000 rpm
Sealing: PP, Three-stage sealing by plastic axial plain washer on both sides
