INA RASEY40-N Plummer Block Housing Unit
New
In stock1 unitReady to ship
Plummer Block Housing Unit
INA RASEY40-N Plummer Block Housing Unit features a 40 mm bore diameter and 179 mm overall length. Made of grey cast iron with a protecting cap (KASK08), it ensures secure bearing support and stability in industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
INA Plummer Block Housing Unit RASEY40-N
The INA Plummer Block Housing Unit RASEY40-N is designed for heavy-duty applications, offering robust housing for bearings with precise alignment and stability. This unit is ideal for providing secure bearing support and protection in industrial environments.
Manufacturer: INA
Type: Plummer Block Housing Unit
Model: RASEY40-N
Housing: GG. ASE08
Bearing Designation: GYE40-XL-KRR-B
| Bore Diameter (d) | 40 mm |
| Overall Length (L) | 179 mm |
| Height (H2) | 99 mm |
| Distance Fixing Bore (J) | 138.25 mm |
| Distance Shaft Axis (H) | 49.2 mm |
| Width (Slot) (N) | 14 mm |
| Length (Slot) (N1) | 26 mm |
| Width (Base) (A) | 48 mm |
| Connection Thread for Lubrication | M6 |
| Groove | N, Cast iron housing with undercut slot for end caps |
| Material | GG, Grey cast iron |
| Protecting Cap | KASK08 |
