INA ZKLN4075-2RS Axial Angular Contact Ball Bearing

Manufacturer: Schaeffler INA

Type: Axial Angular Contact Ball Bearing

Model: ZKLN 4075 2RS

Replaces: ZKLN4075-2RS-XL, ZKLN4075.2RS

Dimensions

Bore Diameter d: 40 mm

Outer diameter D: 75 mm

Width B: 34 mm

Contact angle α: 60 °

Basic load ratings, axial:

Dynamic C_a: 43000 N

Static C_0a: 101000 N

Fatigue load limit, axial: 6100 N

Limiting speed for grease lubrication: 1800 rpm

Thermally safe operating speed: 1800 rpm

Sealing: 2RS, Contact lip seal on both sides

Operating Temperature: -30 … +120 °C
