Klaschka OAS/N/A-M30RG-2/E1S Sensor

Manufacturer: KLASCHKA

Type: Sensor

Model: OAS/N/A-M30RG-2/E1S

Part No.: 111595

Sensing Range: 15 mm

Real Sensing Range: 15 ± 10% mm

Operating Voltage: 90 … 280 V AC

Operating Current: 10 … 240 mA

Switching Output: Normally Closed

Mounting: Non-Flush Mountable

Housing: Threaded type

Protection Class: II

Enclosure rating: IP67

Diameter of Connection: 16.5 mm Connector

Diameter, Housing Length: 30, 94 mm

Ambient Temperature: -25 … 80 °C

Material: Brass white bronze coated; sensing face:PBT

Weight: 0.19 kg
