Metalwork W0952029394 CE3M8P Magnetic Sensor
Manufacturer: METALWORK
Type: Magnetic HALL Sensor
Model: W0952029394
MRN: CE3M8P
Magnetic Sensitivity: 2.8 mT ± 25%
Max. Repeatability: 0.1 mT
Operating Voltage: 10 … 30 V DC
Electrical Design: PNP
Switching Output: Normally open
Current Rating: 100 mA
Power Rating: 3 W
Connector type: Cable
Dimensions: 4.3 x 6.1 x 30.5 mm
Housing: Oval
Housing Material: PA66 + PA6I/6T
Operating Temperature: -25… 75°C
