MGM BM 63B2 Brake Motor

MGM BM63B2 BRAKE MOTOR

The MGM BM63B2 Brake Motor is a high-performance motor designed for various industrial applications. With its 0.25/0.3 kW rated power, 230/400 V rated voltage, and 2800/3350 RPM rated speed, this motor ensures efficient performance and durability. It features a thermal class of F, protection class IP54, and a brake torque of 5 Nm for reliable operation.

Manufacturer: MGM

Type: BRAKE MOTOR

Model: BM63B2

Part No.: 02300791

Technical Specifications

• Rated Power [kW]: 0.25/0.3
• Rated Voltage [V]: 230 delta / 400 star at 50 Hz, 277 delta / 480 star at 60 Hz
• Rated Current [A]: 1.3 / 0.75
• Rated Speed [min-1]: 2800 / 3350
• Frequency [Hz]: 50/60
• Protection Class [IP]: 54
• Thermal Class: F
• Duty: S1
• Power Factor [cos]: 0.76
• Brake Voltage [V]: 230
• Brake Current [A]: 0.2
• Brake Torque [Nm]: 5
