Microphase DC1C-100-10-XXX Servo Drive FOR Brush Motors
Used
In stock1 unitReady to ship
800,00$
SERVO DRIVE FOR BRUSH MOTOR
MICROPHASE DC1C-100-10-XXX servo drive from the DC ONE range supports 900 W rated power, 10 A rated current, and provides precision control features with wide voltage and encoder signal compatibility.10A900WBrushControllerdcDC1C-100-10-XXXDriveEncoderHighMicrophaseMotionmotorOneperformanceSeriesServo
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
MICROPHASE DC1C-100-10-XXX SERVO DRIVE
The DC1C-100-10-XXX from the DC ONE range by MICROPHASE is a high-efficiency servo drive designed specifically for brush motors. It delivers robust performance in automation and motion control systems, with wide voltage compatibility and precise feedback monitoring.
Manufacturer: MICROPHASE
Type: Servo Drive for Brush Motor
Range: DC ONE
Model: DC1C-100-10-XXX
Ref no: 3500RFM 500PPR
| Rated Current | 10 A |
| Peak Current | 20 A |
| Rated Power | 900 W |
| Peak Power | 1800 W |
| Output Voltage | 0.9 V DC |
| PWM Frequency | 20 kHz |
| Operative Temperature | 0 / 40 °C |
| Analog Inputs Range | +/-10 V DC |
| Current Monitor | +/- 8 V DC (At peak current) |
| Velocity Monitor | +/- 8 V DC (At max. velocity) |
| Encoder Power Supply | +5 V DC @130 mA |
| Auxiliary Power Supply | +/-10 V DC @ 4 mA |
| Maximum Encoder Frequency | 300 kHz |
| Logic Level Encoder Inputs | +2.8V / +24V |
| Start Signal (Input Range) | +9V / +30V DC |
| Current Loop Bandwidth | 2 kHz |
| Velocity Loop Bandwidth | 150 Hz |
