Moeller DILM25-22 Contactor

Manufacturer: MOELLER
Type: Contactor
Model: DILM25-22
Part No: 106365

Rated Supply Voltage: 230 … 240 V AC
Frequency: 50 … 60 Hz
Operating Voltage: 24 … 690 V AC
Rated Operation Current:
At AC-1, 400 V : 45 A
At AC-3,400 V : 25 A
 At AC-4,400 V : 13 A
Rated Operation Power:
At AC-3, 400 V : 11 kW
At AC-4, 400 V : 6 kW
Rated impulse withstand voltage (Uimp): 8000 V AC
Contacts: 2Normally Open (NO), 2Normally Close (NC)
Protection: IP 00
Operating Temperature: -25 … 60 °C
Dimensions: 45 x 85 x 138 mm
