Moog GL15 Brushless Servo Motor

Manufacturer: Moog

Type: Brushless Servomotor

Model: GL 15

Rated Voltage [V]:220 V

Rated Speed (n₁) [min^-1]: 50

Rated Speed (n₂) [min^-1]: 550

Rated Current (I₁) [A]: 0.33 A

Rated Current (I₂) [A]: 0.55 A

Maximum Current [A]: 2.0

Constant Voltage [V/1000min^-1]: 121

Rated Pressure [kg/cm²]: 0.4

Thermal Class: F

Explosion Protection Marking: (Ex) Explosion-Proof

Protection Class [IP]: 54

Weight [kg]: 2.15
