Nachi SS-G03-C5-FGR-D2-5224J Solenoid Operated Directional Control Valve
New
In stock2 unitsReady to ship
Solenoid Operated Directional Control Valve
The Nachi SS-G03-C5-FGR-D2-5224J Solenoid Operated Directional Control Valve features 24V DC power, 35 MPa pressure rating, shockless operation, and cascade mounting for industrial hydraulic applications.24v35cascadeControldcDirectionalFluidHydraulicIndustrialMountingMPaNachiPrecisionshocklesssolenoidSS-G03-C5-FGR-D2-5224JValve
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Nachi SS-G03-C5-FGR-D2-5224J Solenoid Operated Directional Control Valve
The Nachi SS-G03-C5-FGR-D2-5224J Solenoid Operated Directional Control Valve is a high-performance hydraulic valve engineered for precise fluid control in industrial applications. With shockless operation, an indicator light, and robust construction, this valve ensures efficient and reliable hydraulic system performance.
Manufacturer: Nachi
Type: Solenoid Operated Directional Control Valve
Model: SS-G03-C5-FGR-D2-5224J
Part No.: 790
| Nominal Diameter | 3 |
| Operation Method | C, Spring Center |
| Auxiliary Symbol | F, Shockless Type with Indicator Light |
| Power Supply | 24 V DC |
| Maximum Working Pressure | 35 MPa |
| Permissible Back Pressure (Port T) | 16 MPa |
| Working Temperature Range | -20 to 70°C |
| Viscosity Range | 15 to 300 mm²/s |
| Filtration | 25 Microns or Less |
| Connection | ½ Inch |
| Mounting Method | G, Cascade Mounting |
