Nidec 115U3C300XAAEA115190-SBTD Servo Motor
Used
In stock1 unitReady to ship
Servo Motor
NIDEC Servo Motor 115U3C300XAAEA115190-SBTD features a rated power of 2.98 kW, rated torque of 9.5 Nm, and maximum speed of 3877 rpm. It operates efficiently within a temperature range of 0-40Ø¢°C and offers excellent durability with protection class IP65 and insulation class F.2.98300038779.5ClassFhigh-precisionIndustrialInsulationIP65kWMaxmotorNmProtectionRatedrpmServoSpeedTorque
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
NIDEC Servo Motor 115U3C300XAAEA115190-SBTD
The NIDEC Servo Motor 115U3C300XAAEA115190-SBTD is a high-performance motor designed for precise control and reliable operation in industrial systems. With a rated power of 2.98 kW, rated torque of 9.5 Nm, and a wide operating range, this motor ensures efficiency and durability in various applications.
Manufacturer: NIDEC
Type: Servo Motor
Model: 115U3C300XAAEA115190-SBTD
Technical Specifications
- Rated Voltage [V]: 380/480
- Rated Power [kW]: 2.98
- Rated Torque [Nm]: 9.5
- Stall Torque [Nm]: 10.8
- Rated Current [A]: 5.9
- Stall Current [A]: 6.8
- Rated Speed [rpm]: 3000
- Max. Speed [rpm]: 3877
- Constant Voltage [V/krpm]: 98
- Constant Torque [Nm/A]: 1.6
- Protection Class [IP]: 65
- Temperature [CØ¢°]: 0-40
- Poles: 6
- Insulation Class: F
