NSK 1205TNG Self-Aligning Ball Bearing
New
In stock1 unitReady to ship
Self-Aligning Ball Bearing
The NSK 1205TNG bearing features a 25 mm bore diameter, 52 mm outer diameter, and a polyamide solid cage, providing reliable operation and misalignment compensation.1205TNG2552BallbearingboreCageCompensationdiameterdurableHigh-SpeedMisalignmentmmNSKOuterPolyamideSelf-Aligning
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
NSK 1205TNG Self-Aligning Ball Bearing
The NSK 1205TNG Self-Aligning Ball Bearing is designed to accommodate misalignment and reduce friction, ensuring smooth operation in high-speed and high-load applications. With a polyamide solid cage, this bearing provides excellent durability and reliable performance.
Manufacturer: NSK
Type: SELF-ALIGNING BALL BEARING
Model: 1205TNG
| Bore Diameter (d) | 25 mm |
| Outer Diameter (D) | 52 mm |
| Width (B) | 15 mm |
| Dynamic Load Rating (Cr) | 12.20 kN |
| Static Load Rating (C0r) | 3.35 kN |
| Limiting Speed (Oil) | 16000 rpm |
| Limiting Speed (Grease) | 13000 rpm |
| Cage | TNG, Solid cage of polyamide |
