NTN 1309SKC3 Self-Aligning Ball Bearing
New
In stock4 unitsReady to ship
Self-Aligning Ball Bearing
The NTN 1309SKC3 is a robust self-aligning ball bearing with a 45 mm bore, C3 clearance, and pressed steel cage. It supports up to 7500 rpm with oil and is suited for high-speed, misaligned shaft applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
NTN 1309SKC3 Self-Aligning Ball Bearing
The NTN 1309SKC3 is a high-performance self-aligning ball bearing engineered to accommodate misalignment and shaft deflection. Featuring a pressed steel cage, tapered K-type bore, and C3 internal clearance, it is ideal for high-speed, high-precision industrial applications.
Manufacturer: NTN
Type: Self-Aligning Ball Bearing
Model: 1309SKC3
| Bore Diameter (d) | 45 mm |
| Outer Diameter (D) | 100 mm |
| Width | 25 mm |
| Dynamic Load Rating | 38.5 kN |
| Static Load Rating | 12.7 kN |
| Fatigue Load Limit | 0.33 kN |
| Oil Lubrication Limit Speed | 7500 tr/min |
| Grease Lubrication Limit Speed | 6000 tr/min |
| Cage | Pressed Steel |
| Bore Type | K, Tapered Bore, Open |
| Clearance | C3 |
