NTN 51113 Thrust Ball Bearing

Manufacturer: NTN

Type: Single Direction Thrust Ball Bearings

Model: 51113

Dimensions

Bore diameter d: 65 mm

Outer diameter D: 90 mm

Height T: 18 mm

Outside diameter shaft washer d₁: 90 mm

Inner diameter housing washer D₁: 67 mm

Minimum chamfer dimension r_{s min}: 1 mm

Basic load ratings:

Dynamic C_a: 41500 N

Static C_0a: 117000 N

Allowable speed:

Grease lubrication: 2400 rpm

Oil lubrication: 3500 rpm
