Phoenix Contact PSR-SPP-24UC/ESAM4/8X1/1X2 Safety Relay

Available on request

299,99$

Safety Relay

A compact and reliable safety relay designed for emergency stop and safety door applications, providing fast response times, multiple safety-related outputs, and dependable performance in industrial automation systems.

Manufacturer
PHOENIX CONTACT
SKU
1084782
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

Phoenix Contact PSR-SPP-24UC/ESAM4/8X1/1X2 Safety Relay

A high-reliability safety relay from Phoenix Contact designed for critical safety applications such as emergency stop circuits and safety doors. Part of the PSRclassic product family, this relay ensures dependable monitoring, fast response times, and robust industrial performance in automation and machine safety systems. Manufacturer: Phoenix Contact

Type: Safety Relay

Model: PSR-SPP-24UC/ESAM4/8X1/1X2

Item No.: 2963996

Product Family: PSRclassic

Application: Emergency Stop, Safety Door

Timing Characteristics

Mechanical & Environmental Data

Rated Insulation Voltage250 V
DesignationA1/A2
Rated Control Circuit Supply Voltage (US)24 V DC -15 % / +10 %
Rated Control Supply Current (IS)typ. 100 mA (at US)
Power Consumption at UStyp. 2.4 W
Inrush Currenttyp. 3.5 A
Description of InputSafety-related
Number of Inputs3
Input Voltage Range "0" Signal0 V DC / 5 V DC
Control1 and 2 channel
Output Description2 N/O contacts each in series, safety-related, floating
Number of Outputs8
Contact Switching Type8 enabling current paths
Contact MaterialAgSnO2
Typical Response Time140 ms
Response Time (US Autostart)120 ms
Typical Starting Time with US200 ms
Typical Release Time20 ms
Release Time (At US / On Demand via A1)50 ms
Restart Time1 s
Maximum Power Dissipation (Nominal)31.7 W
Width45 mm
Height112 mm
Depth114.5 mm
Housing MaterialPA
Ambient Temperature (Operation)-20 °C / +55 °C
NoteRelay bases and sockets for various relay types are available. For compatible options, please contact us directly or visit our website to view all available models.
