Phoenix Contact SACC-M12MS-4CON-PG7-M Connector
Phoenix Contact Connector SACC-M12MS-4CON-PG7-M
The Phoenix Contact Connector SACC-M12MS-4CON-PG7-M is designed for reliable industrial connections with a nominal voltage of 250 V AC/DC, 4 A current, and IP67 protection.Phoenix Contact Connector SACC-M12MS-4CON-PG7-M
The Phoenix Contact Connector SACC-M12MS-4CON-PG7-M is designed for industrial applications, providing reliable and efficient connections. This connector features a rated surge voltage of 2.5 kV and an insulation resistance of 100 MΩ, making it ideal for high-performance environments. It supports a nominal voltage of 250 V AC/DC and a nominal current of 4 A. The M12 plug design with a straight cable outlet ensures easy integration into various industrial systems. The connector is made with high-quality zinc die-cast, nickel-plated materials for durability and features a degree of protection of IP67 for reliable performance in harsh environments.
Manufacturer: Phoenix Contact
Type: Connector
Model: SACC-M12MS-4CON-PG7-M
This high-quality connector ensures secure connections in demanding industrial environments, offering durability and protection against environmental factors.
| Rated Surge Voltage | 2.5 kV |
| Contact Resistance | 8 mΩ |
| Insulation Resistance | 100 MΩ |
| Nominal Voltage (UN) | 250 V AC/DC |
| Nominal Current (IN) | 4 A |
| Head Design | Plug |
| Head Cable Outlet | Straight |
| Head Thread Type | M12 |
| Sensor Type | Universal |
| Number of Positions | 4 |
| Number of Cable Outlets | 1 |
| Cable Outlet | Straight |
| Pg Screw Connection | Pg7 |
| Degree of Pollution | 3 |
| Connection Method | Screw connection |
| Material for Screw Connection | Zinc die-cast, nickel-plated |
| Stripping Length of the Individual Wire | 5 mm |
| Degree of Protection | IP67 |
| Ambient Temperature (Operation) | -40 °C to +85 °C |
| Outside Diameter | 4 mm to 6 mm |
| Dimensions (H x W x L) | 20 x 20 x 60 mm |
