Pizzato FD 535-1K21 Position Switch

Name: PIZZATO FD 535-1K21 POSITION SWITCH
SKU: 1105058
Availability: LimitedAvailability

pizzato-FD-535-1K21-position-switch-(new-with-carton)

pizzato-FD-535-1K21-position-switch-(new-with-carton)-1

pizzato-FD-535-1K21-position-switch-(new-with-carton)-2

pizzato-FD-535-1K21-position-switch-(new-with-carton)-3

pizzato-FD-535-1K21-position-switch-(new-with-carton)-4

pizzato-FD-535-1K21-position-switch-(new-with-carton)-5

New

In stock1 unitReady to ship

with adjustable roller lever, 1NO + 1NC contacts, 400 V AC, 3 A rated current, metal housing, and IP67 protection. Suitable for industrial position detection and automation systems.

Manufacturer

PIZZATO

SKU

1105058

Category

Limit Switches

Condition

New

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Code	D10 FD1-20832
Series	FD
Rated Voltage	400 V AC
Rated Current	3 A
Actuator Type	Offset Roller
Rated Thermal Current	10 A
Frequency	50 … 60 Hz
Contact	1 Normally Open (NO) + 1 Normally Closed (NC)
Housing Material	Metal one threaded PG 13
Protection Class	IP67
Temperature	-25 … 80 °C
Standard	IE C 60947-5-1
Dimensions	122.2 x 40 x 36.5 mm
Condition	New
Stock key	CON003
SKU	1105058
Weight	0,34
