Rexroth R900707269 Directional Control Valve
BOSCH REXROTH Directional Control Valve 4 WE 6 R62/EG24N9K4K “ Electrically actuated hydraulic valve with NG 6 size, 350 bar pressure, and 70 l/min flow rate. Designed for precision and reliability in industrial applications.
BOSCH REXROTH Directional Control Valve 4 WE 6 R62/EG24N9K4K
Manufacturer: BOSCH REXROTH
Type: Directional Control Valve
Model: 4 WE 6 R62/EG24N9K4K
MRN: R900707269
The BOSCH REXROTH Directional Control Valve 4 WE 6 R62/EG24N9K4K is a high-performance, electrically actuated valve designed for precision control in hydraulic systems. This valve features a nominal size NG 6 and is capable of handling high pressures and flow rates, making it ideal for demanding industrial applications.
Technical Specifications:
- Nominal Size: NG 6
- Type of Actuation: Electrically
- Max. Working Pressure (Port P, A, B): 350 bar
- Max. Pressure (Port T): 210 bar
- Nominal Flow Rate: 70 l/min
- Hydraulic Connection: Sub-Plate
- Fluid Temperature Range: -20 / +80 °C
- Nominal Voltage per Coil: 24 VDC
Engineered for reliability and precision, this valve provides exceptional performance in controlling hydraulic flow and direction, making it suitable for industrial systems requiring robust and accurate operation.
