Sandvik R166.OG-16MM01-200 Insert FOR Thread Turning

Name: SANDVIK R166.OG-16MM01-200 INSERT FOR THREAD TURNING
SKU: 978327
Availability: LimitedAvailability

sandvik-r166-og-16mm01-200-insert-for-thread-turning-1-2

sandvik-r166-og-16mm01-200-insert-for-thread-turning-2-2

sandvik-r166-og-16mm01-200-insert-for-thread-turning-3-2

sandvik-r166-og-16mm01-200-insert-for-thread-turning-4-2

sandvik-r166-og-16mm01-200-insert-for-thread-turning-5-2

sandvik-r166-og-16mm01-200-insert-for-thread-turning-6-2

New

In stock1 unitReady to ship

SKU

978327

Category

Inserts

Condition

New

cutting insert Inserts Sandvik tools

Massive Inventory

Global Shipping

Expert Support

Quality Guaranteed

Manufacturer: SANDVIK

Type: Insert for Thread Turning

ISO: R166.0G-16MM01-200 1020

ANSI: R166.0G-16MM01-200 1020

Material Id: 5741740

Standard number (STDNO1): ISO 965-1998

Thread type (TTP): EXT

Thread pitch (TP): 2mm

Thread profile type (TPT): F

Tooth count (NT): 1

Thread tolerance class (TCTR)IT: 6

Theoretical thread height (HA): 1.5 mm

Thread height difference (HB): 0.29 mm

Profile distance ex (PDX): 1.4 mm

Profile distance ey (PDY): 1.32 mm

Insert mounting style code (IFS): 3

Insert size and shape (CUTINTSIZESHAPE): U-Lock 166/154 -external size 16R

Cutting edge count (CEDC): 3

Inscribed circle diameter (IC): 9.525 mm

Hand (HAND): R

Grade (GRADE): 1020

Substrate (SUBSTRATE): HC

Coating (COATING): PVD TIN

Insert thickness (S): 3.969 mm

Weight: 0.06 kg
