Schneider A9N19456 Single Differential Lock Part

Manufacturer: SCHNEIDER ELECTRIC

Type: SINGLE DIFFERENTIAL LOCK PART

Model: A9N19456

Application: Suitable For Residential And Tertiary Applications

Type of differential protection: A

Device name: Vigi C40

Voltage: 400 V AC, phase to phase

Rated current: 40 A

NO. Of Poles: 3P + N

neutral position: Left

Rated Frequency: 50 Hz

Impulse Withstand Voltage Uimp: 4 kV

Connection: Cage Terminals For Rigid Cable Up to 16 mm²

Tripping Due To a Fault Is Indicated: by a red mechanical indicator on the reset lever of the Vigi block

differential sensitivity: 30 mA

Weight: 0.215 kg
