Schneider A9N19499 Differential Lock Part

Manufacturer: SCHNEIDER ELECTRIC

Type: Differential Lock Part

Model: A9N19499

Rated Operational Voltage: 230 V AC

No. Of Poles: 1P + N

Rated current: 40 A

Differential Sensitivity: 300 mA

Residual Current Release Technology: Independent of voltage

Type Of Differential Protection: Type A-SI

Mounting Method: Hooking

Tightening torque: 2 Nm

Rated Insulation Voltage: 440 V AC

Dimensions ( height x width x depth ): 82 x 18 x 70 mm

Frequency: 50 Hz

Operating Temperature: -25 … 60 ° C

Weight: 0.12 kg
