Schneider BCH0802O12F1C AC Servo Motor

Manufacturer: Schneider Electric, Elau

Type: AC Servo Motors

Model: BCH0802O12F1C



Rated Torque [Nm]: 2.39

Rated Current [A]: 5.1

Max Current [A]: 15.3

Rated Voltage [V]: 110

Rated Power [W]: 750

Rated Speed [rpm]: 3000

Max Speed [rpm]: 5000

Holding Torque [Nm]: 2.5

Shaft End: Keyed

Flange Size [mm]: 80

Shaft Diameter [mm]: 19

Shaft Length [mm]: 37

Key Width [mm]: 6

Protection Class [IP]: 65

Thermal Class: A

Weight [kg]: 3.83
