Schneider BMI1003P06A Servo Motor

Manufacturer: Schneider Electric, Elau

Type: Servo Motor

Model: BMI1003P06A

Supply Voltage [V]: 208-400-480

Rated Current [A]: 5.0-5.1-4.7

Rated Power [W]: 1130-2000-2000

Rated Speed [rpm]: 1500-3000-3600

Max. Speed [rpm]: 6000

Stall Torque [Nm]: 7.31-6.55-6.04

Ambient Temperature [°C]: 40

Frequency [Hz]: 50/60

Flange Size [mm]: 100

Shaft Diameter [mm]: 19

Shaft Length [mm]: 40

Protection Class [IP]: 54

Thermal Class: F

Weight [kg]: 10.055
