Schneider Electric TSXASZ401 Analog Output Module

Schneider Electric Analog Output Module TSXASZ401

The Schneider Electric Analog Output Module (Model: TSXASZ401) is designed for the Modicon TSX Micro automation platform. It features 4 analog outputs with types of ±10 V and 0…10 V. The module offers 11-bit analog-to-digital conversion for the 0…10 V range and ±10 V with sign. It boasts a fast response time of 400 µs and protection from short-circuits. The module also ensures electrical isolation with a 1000 V AC isolation voltage, adhering to the IEC 61131-2 standard. With a low current consumption of 90 mA, it provides efficient operation in automation systems.

🔧 Technical Specifications:

• Manufacturer: Schneider Electric
• Type: Analog Output Module
• Model: TSXASZ401
• Range: Modicon TSX Micro automation platform
• Number of Analog Outputs: 4
• Analog Output Type: ±10 V, 0…10 V
• Analog/Digital Conversion: 11 bits 0…10 V, 11 bits ±10 V with sign
• Response Time: 400 µs
• Protection Type: Short-circuit
• Current Consumption: 90 mA
• Isolation Voltage: 1000 V AC
• Standard: IEC 61131-2
