Schneider Nsyccothd Double Thermostat
The Schneider NSYCCOTHD Double Thermostat efficiently controls a resistance heater and a fan with 250V AC, 120V AC rated voltage, 10A/15A current, NO+NC contacts, and operates between 0 and 60°C.
Schneider NSYCCOTHD Double Thermostat
The Schneider NSYCCOTHD Double Thermostat is designed for controlling a resistance heater and a fan, providing an efficient solution for temperature regulation in various applications. This model supports both 250V AC and 120V AC rated voltages, with current ratings of 10A and 15A, respectively. The thermostat operates within a frequency range of 50 to 60Hz, offering reliability and stability in controlling your heating and cooling systems. Equipped with both Normally Open (NO) and Normally Closed (NC) contacts, it provides versatile functionality for managing the on/off switching of connected devices. With a power rating of 30W DC, the NSYCCOTHD ensures low energy consumption while maintaining precise control over the connected equipment. The thermostat is built to operate effectively in ambient temperatures ranging from 0 to 60°C, making it suitable for a wide range of environments.
- Manufacturer: Schneider
- Type: Double Thermostat
- Model: NSYCCOTHD
Technical Specifications:
- Function: Control a Resistance Heater and a Fan
- Rated Voltage: 250V AC, 120V AC
- Rated Current: 10A, 15A
- Frequency: 50-60Hz
- Contact: NO+NC
- Power: 30W DC
- Operating Temperature: 0 to 60°C
The Schneider NSYCCOTHD Double Thermostat is the ideal solution for applications requiring precise control of heating and cooling equipment, ensuring reliable performance and energy efficiency in various environments.
