Sick DFS60B-S4EA00005 Incremental Encoder
New
In stock1 unitReady to ship
125,00$
INCREMENTAL ENCODER
Sick DFS60BS4EA00005 delivers precise motion control with stainless steel shaft, 600 kHz output frequency, and HTL/push-pull interface. Built for industrial-grade performance and harsh environments.10372606-ChannelAluminumCastConnectorControlDFS60BS4EA00005DieEncoderFeedbackHTLIncrementalIndustrialIP65M23MotionPrecisionshaftSickSpeed
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SICK DFS60BS4EA00005 INCREMENTAL ENCODER
The Sick DFS60BS4EA00005 is a high-precision incremental encoder designed for demanding industrial environments. Built with a rugged aluminum die-cast housing and stainless steel shaft, it ensures accurate positioning and speed feedback even under tough conditions.
Manufacturer: Sick
Type: Incremental Encoder
Model: DFS60BS4EA00005
Part No.: 1037260 1812-5037
| Operating Voltage | 10 / 32 V |
| Load Current Max. | 30 mA |
| Power Consumption | 0.5 W |
| Mechanical Interface | Solid Shaft, Face Mount Flange |
| Shaft Diameter / Length | 10 mm / 19 mm |
| Shaft Material | Stainless Steel |
| Operating Speed | ‰¤ 9,000 min»¹ |
| Angular Acceleration | ‰¤ 500,000 rad/s² |
| Operating Torque | 0.3 Ncm |
| Housing Material | Aluminum Die Cast |
| Communication Interface | Incremental (HTL / Push Pull) |
| Signal Channels | 6-Channel |
| Connection Type | Male Connector, M23, 12-Pin, Radial |
| Max Output Frequency | 600 kHz |
| Pulses per Revolution | 5 |
| Working Temperature | -30 / 100 °C |
| Enclosure Rating | IP65 |
