Sick FX3-XTIO84002 Safety Systems FOR Agvs AND Amrs

Manufacturer: SICK

Type: Safety systems for AGVs and AMRs

Model: FX3-XTIO84002

Part No.: 1044125

Supply Voltage: 24 V DC

Voltage supply: Via A1, A2

Supply voltage: 24 V DC (16.8 V DC … 30 V DC)

Safety Integral Level: SIL3

Number of safety inputs: 8

Number of test outputs: 2

Number of safe outputs: 4

Input voltage HIGH: 13 V DC … 30 V DC

Input voltage LOW: -5 V DC … 5 V DC

Input current HIGH: 2.4 mA … 3.8 mA

Input current LOW: -2.5 mA … 2.1 mA

Type of supply voltage: PELV or SELV

Type of output: PNP semiconductors, short-circuit protected

Output voltage HIGH: 16 V DC … 30 V DC

Output current: ≤ 2 A

Dimension: 22.5 x 96.5 x 120.6 mm
