SICK OD2-P85W20I0 Displacement Sensor

In stock1 unitReady to ship

499,99$

Displacement Sensor The SICK OD2-P85W20I0 is a precision laser displacement sensor with a 65–105 mm measuring range, fast response, and reliable PNP and analog outputs for industrial automation applications.

Manufacturer
SICK
SKU
1100980
Category
Sensors
Condition
New
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Part No.6 036 613
code1208X 17839, 1208839165X
Supply voltage UBDC 12 V ... 24 V
Power consumption2.88 W
Warm-up time30 min
DisplayDistance bar graph, up to 8 status LEDs
Enclosure ratingIP67
Protection classIII
Connection typeMale connector, M12, 8-pin
Measuring range65 mm ... 105 mm
Repeatability10 µm
Linearity± 40 µm
Response time1 ms
Measuring frequency2 kHz
Output time0.5 ms
Emitted beamLight source Laser, red
Typ. light spot size (distance)0.8 mm x 1.3 mm (85 mm)
StandardIEC 60825-1:2014, EN 60825-1:2014
Laser class2
Digital output Number2
Maximum output current IA100 mA
Analog output Number1
Current4 mA ... 20 mA, = 300 O
Resolution16 bit Multifunctional input (MF) 1 x MF
Dimensions (W x H x D)20.4 mm x 60 mm x 50 mm
Housing materialPlastic (PBT)
Window materialPlastic (PMMA)
Ambient temperature, operation–10 °C ... +40 °C
Stock keyCON003
ConditionNew
SKU1100980
Weight0,11
