Siemens 1FT5076-0AF71-2-Z Synchronous Servo Motor
Used
In stock1 unitReady to ship
SYNCHRONOUS SERVO MOTOR
Siemens 1FT5076-0AF71-2-Z is a high-performance synchronous servo motor with 18 Nm rated torque, 375 V, and 3000 rpm speed. Ideal for precision automation with IP64 protection and S1 continuous duty.1FT5076-0AF71-2-Z375VAutomationB5ContinuousDutyHighIndustrialIP64motormountServoSiemensSynchronousTorque
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SIEMENS 1FT5076-0AF71-2-Z SYNCHRONOUS SERVO MOTOR
Designed for high-performance automation systems, the Siemens 1FT5076-0AF71-2-Z synchronous servo motor delivers precise motion control and continuous torque stability. Built for durability and accuracy in industrial operations, this motor integrates seamlessly with dynamic motion systems.
Manufacturer: Siemens
Type: Synchronous Servo Motor
Model: 1FT5076-0AF71-2-Z
Part No.: D362 5007 02 002
Series: 5
Frame Size: 07
Length: 6
| Rated Voltage | 375 V |
| Rated Torque | 18 Nm |
| Rated Speed | 3000 rpm |
| Standstill Current | 17 / 20.5 A |
| Standstill Torque | 18 / 22 Nm |
| Constant Voltage | 13.3 mVmin |
| Duty | S1 Continuous |
| Mounting Position [IM] | B5 |
| Protection Class | IP64 |
| Tacho Generator | 1FU1050-6CF |
| Thermal Class | F |
