Siemens 3RP1505-1BP30 Time Relay
New
In stock1 unitReady to ship
Time Relay The Siemens 3RP1505-1BP30 is a SIRIUS 3RP15 time relay with a 0.05 s to 100 h timing range and two change-over contacts for industrial control applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Range | SIRIUS |
| Series | 3RP15 |
| Control Supply Voltage | 200 … 240 V AC / 24 V AC/DC |
| Thermal Current | 5 A |
| Frequency | 50 … 60 Hz |
| Power Loss Max. | 2 W |
| Auxiliary Contact | 2 Change-Over (CO) |
| Contact Operational Rating | 24 / 250 V AC, 3A / 24 V DC, 1 A / 125 V DC, 0.2 A / 250 V DC, 0.1 A |
| Time Range | 0.05 s … 100 h |
| Protection Class | IP20 |
| Ambient Temperature | -25 … 60 °C |
| Dimensions | 102 x 22.5 x 91 mm |
| Stock Key | CON003 |
| Condition | New |
| SKU | 1104134 |
| Weight | 0,13 |
